Available on back-order
Managed Gigabit Ethernet switch with 7 10/100BaseT(X) ports, and 3 SFP slots for adding SFP-1G series Gigabit Ethernet modules, -40 to 75°C operating temperature
The EDS-510A Gigabit managed redundant Ethernet switches are equipped with up to 3 Gigabit Ethernet ports, making them ideal for building a Gigabit Turbo Ring, but leaving a spare Gigabit port for uplink use. The Ethernet redundancy technologies, Turbo Ring and Turbo Chain (recovery time < 20 ms), RSTP/STP, and MSTP, can increase system reliability and the availability of your network backbone.
The EDS-510A Series is designed especially for communication demanding applications such as process control, shipbuilding, ITS, and DCS systems, which can benefit from a scalable backbone construction.
Command line interface (CLI) for quickly configuring major managed functions
DHCP Option 82 for IP address assignment with different policies
Supports EtherNet/IP and Modbus TCP protocols for device management and monitoring
IGMP snooping and GMRP for filtering multicast traffic
Port-based VLAN, IEEE 802.1Q VLAN, and GVRP to ease network planning
QoS (IEEE 802.1p/1Q and TOS/DiffServ) to increase determinism
Port Trunking for optimum bandwidth utilization
SNMPv1/v2c/v3 for different levels of network management
RMON for proactive and efficient network monitoring
Bandwidth management to prevent unpredictable network status
Lock port function for blocking unauthorized access based on MAC address
Automatic warning by exception through email and relay output
Alarm Contact Channels | 2, Relay output with current carrying capacity of 1 A @ 24 VDC |
---|---|
1000BaseSFP Slots | |
Filter | |
Industrial Protocols | |
IGMP Groups | |
LED Indicators | PWR1, PWR2, FAULT, 10/100M (TP port), 1000M (Gigabit port), MSTR/HEAD, CPLR/TAIL |
Console Port | |
Ethernet Interface | |
Connection | |
Input Current | |
Input Voltage | |
Overload Current Protection | |
Housing | |
IP Rating | |
Operating Temperature | -40 to 75°C (-40 to 167°F) |
Safety | |
Hazardous Locations | |
EMC | |
EMI | |
Traffic Control | |
Shock | |
Freefall | |
Vibration | |
Time | |
Standards | |
Warranty Period | |
Details | |
Installation |
